LM311

Riding Greens Mower

LM311 is a riding diesel engine lawn mower for mowing golf course greens. It is completely hydraulic and the blades are also hydraulically driven. The rotation speed of the blade can be adjusted steplessly, allowing you to smoothly and quickly change the rotation speed according to the grass conditions.

Features

  • Equipped with "B-ACT", it is possible to change the mowing posture according to the grass condition.
  • The levers to be operated are placed on the right-hand control panel for easy operation.
  • The mower unit can be raised and lowered using the joystick, allowing the operator to raise and lower the mower unit without shifting his/her line of sight.
  • Each cover including the bonnet can be fully opened, making it easy to maintain. Daily inspections can be done easily and in a short time.

Specification

Type for greens
Dimensions Total length 250 cm
Total width 191 cm
Total height Steering wheel 140 cm
ROPS 195 cm
Weight Machine:2WD
(empty fuel tank)		 without ROPS, Grass catcher, Groomer 682 kg
Machine:3WD
(empty fuel tank)		 without ROPS, Grass catcher, Groomer 709 kg
Grass catchers (for one machine) 15 kg
Groomers (for one machine) 10 kg
ROPS + Seatbelt ―
Minimum turning radius 161 cm
Engine Model Kubota D722-E4B
Type Vertical water-cooled 4-cycle diesel engine
Total displacement 719 cm3 (0.719 L)
Maximum output ―
Rated output 12.4 kW (16.9 PS)/3,000 rpm
Fuel tank capacity Diesel 20.0 dm3 (20.0 L)
Operating width (Mowing width) 157 cm
Operating height (Mowing height) 1.5 - 18.0 mm
Number of Blades 11
Drive Traveling HST 2WD [3WD (2WD/3WD selectable)]
Mowing Hydraulic
Speed (HST) Forward 0 – 15.0 km/h
Reverse 0 - 6.0 km/h
［2WD selection of 3WD model : 0 - 9.0 km/h］
Efficiency 7,536 m2/h (6.0 km/h x mowing width x 0.8)

※The factory default maximum engine rpm is 3,000 rpm.
